> Lattice ispmach IM4A3-128/64 10YC-12YI cpld mach 4A gal
Lattice ispmach IM4A3-128/64 10YC-12YI cpld mach 4A gal
I am placing these on sale for 99 cents.
It is up to you to be certain that these are the devices that you need. These were ordered by the original purchaser, pre-programmed, but have never been used. E2CMOS devices are reprogrammable. I have included some information from the datasheet below, however more data can be found here:
http:// /datasheet-pdf/pdf/70305/LATTICE/M4A3-128/64-10CAI.html
http:// /lit/docs/datasheets/cpld/ispm4a.pdf
High-performance, E2CMOS 3.3-V & 5-V CPLD families
Flexible architecture for rapid logic designs
* Excellent First-Time-FitTM and refit feature
* SpeedLockingTM performance for guaranteed fixed timing
* Central, input and output switch matrices for 100% routability and 100% pin-out retention
* 5.0ns tPD Commercial and 7.5ns tPD Industrial
32 to 512 macrocells; 32 to 768 registers
44 to 388 pins in PLCC, PQFP, TQFP, BGA, fpBGA and caBGA packages
Flexible architecture for a wide range of design styles
* Synchronous or asynchronous mode
Advanced capabilities for easy system integration
* 3.3-V & 5-V JEDEC-compliant operations
* JTAG (IEEE 1149.1) compliant for boundary scan testing
* 3.3-V & 5-V JTAG in-system programming
* PCI compliant (-5/-55/-6/-65/-7/-10/-12 speed grades)
* Safe for mixed supply voltage system designs
* Programmable pull-up or Bus-FriendlyTM inputs and I/Os
* Individual output slew rate control
Advanced E2CMOS process provides high-performance, cost-effective solutions
Supported by ispDesignEXPERTTM software for rapid logic development
* Supports HDL design methodologies with results optimized for ispMACH 4A
* Flexibility to adapt to user requirements
Lattice and third-party hardware programming support
* LatticePROTM software for in-system programmability support on PCs and automated test equipment
* Programming support on all major programmers including Data I/O, BP Microsystems, Advin, and System General
HIGH-DENSITY PROGRAMMABLE LOGIC.
HIGH-PERFORMANCE E2CMOS TECHNOLOGY.
I originally bought these for use in my Tandy Radio Shack TRS-80 Color Computer 1 2 and 3 projects (see my other items).
OTHER STUFF HERE: Check out my other items!
I also sell various types of EPROMs which may also be useful to you in your projects. I include the device programming for free. The following are some interesting observations regarding EPROM substitutions: A 27C256 EPROM CAN BE USED IN PLACE OF A 27C128 OR 27C64. TO USE A 27256 IN PLACE OF A 2764, YOU SIMPLY PROGRAM THE 8K IMAGE (THE 2764 IMAGE) INTO THE 27256 FOUR TIMES. TO USE A 27256 IN PLACE OF A 27128, YOU SIMPLY PROGRAM THE 16K IMAGE (THE 27128 IMAGE) INTO THE 27256 TWO TIMES. I ALSO INCLUDE THIS SERVICE FREE - I WILL TAKE YOUR 8K OR 16K IMAGE AND "STACK" IT INTO A 32K IMAGE SUITABLE FOR PROGRAMMING INTO A 32Kx8 EPROM (27C256 OR EQUIVALENT.) I WILL THEN EMAIL YOU THE "STACKED" IMAGE. THE RESULTING EPROM CAN THEN BE USED AS IF IT WERE A 2764 OR 27128. I GUARANTEE THAT THIS METHOD WORKS PERFECTLY - I USE THIS METHOD ALL OF THE TIME BECAUSE I HAVE MORE 27C256 EPROMS THAN ANY OTHER TYPE.
