Cree xlamp® mc-e led white 430LM ~ 490LM star board
CREE XLamp MC-E LED White 430LM ~ 490LM Star Board
The Cree XLamp MC-E LED is a lighting-class, multi-chip LED that provides high lumen output in a small footprint package. Compared to discrete LEDs, XLamp MC-E LEDs reduce the distance between LED die, creating a small optical source for excellent optical control and efficient color mixing.
DC Forward Voltage (VF): 12Vdc ~ 15 Vdc
DC Forward Current (IF): 350mA ~ 700mA
Internal Connecting: Serial Soldering
Intensity Luminous (Iv): 430LM ~ 490LM
Low thermal resistance: 3 C/W
Electrically-isolated thermal path
