> Lvo FL14G stainless gas front load pan washer
Lvo FL14G stainless gas front load pan washer
LVO FL14G Stainless Gas Front Load Pan Washer
LVO Stainless Gas Front Load Pan Washer
Model No. FL14G Serial No. 2211-0503-2870
Please see pics of cut-off pipes and small damages, and physical condition
Water pump is working along with the control. Removed from working environment. Water inlets are cut-off, need to be replaced in order to work, and gas pipe need to be replaced. All the switches turn on.
Gas Type: Nat. Gas input: (BTU) 48.000 Inlet Pressure: 7"W.C. Main Manifold Pressure: 6" W.C. Main Burner: .082
Wash temp max. 150F 208V-3Ph-60Hz
Rinse Temp. 180F-195F Full Load Amps: 54
Wash Period(min) 3mins Motor Hp: 10
Rinse Period(min) 60sec Other Loads:27/ motor loads: 27
Wash Pressure 45 to 65 PSIG Min. Circuit Conductor Capacity 60.8
Rinse Pressure(min) 20PSIG Max. Rating Branch Circuit Fuse 70
Approx. Dims: 60x46x93 Approx. Weight: 980 lbs
