New 16" swg 60" cc gmc cnc-1660F cnc lathe, fanuc 0I-ma
16" Swg 60" cc GMC CNC-1660F NEW CNC LATHE, Fanuc 0i-Ma
16" Swing 60" Centers GMC CNC-1660F NEW CNC LATHE, Fanuc 0i-Mate, Constant Surface Speed, D1-6 Spdl
HIGH SPEED CNC LATHE w/ Fanuc Oi-Mate Control
Model: CNC-1660F Made in Taiwan
Easy-to-use FANUC Oi-mate CNC control
CNC programmable spindle speeds from 45 to 2,500 rpm
CSS - Constant Surface Speed Programming
Large spindle bore 2-1/16 , D1-6
Full enclosure safety front and rear guards
One-piece solid cast iron machine base
Heavy Duty guideway width 11 13/16
Electrical automatic 4-way turret toolpost
Manual Pulse Generator Handwheel for X & Z
Can use standard flash card for transfer programs and networking FTP
Easy to use Conversational Programming
leads you through programming your part, just fill in
the blanks and check the graphical display. Select from
all canned cycles, such as, profiling, material removing,
roughing and finishing, inside & outside threading, line, arc,
drilling and floating tapping, cut-off, grooving, radius, chamfering
Tool length & radius compensation
Spindle is balanced, hardened and precision ground
Spindle is supported at 3-point by high precision bearings
All gears and shafts are hardened and precision ground
Guideways induction hardened and precision ground
Automatic lubrication system for ballscrews and guideways
Automatic lubrication system in headstock and feed box
Max. swing over cross slide: 7-1/16
Max. turning diameter over bed: 11-3/4
Taper of spindle center: M.T.# 6
Spindle speeds, CNC programmable: 45 2,500 rpm
Diameter of tailstock quill: 2 -1/8
Max. travel of tailstock quill (manual): 4-3/4
Taper of tailstock quill center: M.T. # 4
Auto turret toolpost: 4 positions
Max. tool size for auto turret toolpost: x
Max. travel for Z axis: 51-1/8
Main motor: 6 HP, 220V , 3 or 1 phase
Coolant pump: 1/8 HP , 220V , 1 phase
Auto lubrication: 1/16 HP , 220V , 1 phase
Net Weight, approx.: 5,950 LBS
Overall Dimensions, LxWxH: 106 x 50 x 66
10 manual 3-jaw chuck with set reversible jaws
Electric automatic turret 4-position toolpost
Handwheel (Manual Pulse Generator) for both X & Z axis movement
8 wedge-type hydraulic 3-jaw chuck (non thru hole# D6-3H08)
One year service certificate including labor warranty for FANUC
One day on-site training for FANUC 0i-Mate CNC control
