> Rgb led ribbon strip 200 inches w/ power & controller
Rgb led ribbon strip 200 inches w/ power & controller
RGB LED Ribbon Strip 200 inches w/ power & controller
RGB LED Ribbon Strip 200 inches / roll
Bundled with 12V DC Power Supply
Bundled with RGB color controller
Weatherproof Gel protective jacket
Tape base for easy installation
Best for showcase products, decorating party/meeting rooms, and easily upgrade a architectural, or sign letter project
Tolerance is 0.25 unless otherwise noted
Electrical / Optical characteristics at Ta=25 C degree
Forward Voltage DC (VF): 3000mA, 12V
Dominant Wavelength (nm): 1000mA (R: 620nm - 635nm, G: 515nm - 530nm, B: 460nm - 475nm)
Luminous Intensity (IV): 1000mA (R: 320mcd - 500mcd, G: 680mcd - 900mcd, B: 150mcd - 200mcd)
Operating Temperature: -25C - +60C degree
Storage Temperature: -40C - +100C degree
Ribbon packaged inside a nice protective bag
Price include a 12DC power supply
Price include a RGB Color Controller
Total 6 operation modes had been set up. You can select operation mode by pushing the red button. When power on, this controller is automatically into operation mode1. Pushing the red button one times switch to mode 2, pushing the red button the 2nd times switch to mode3 Pushing the red button the 6th times return to mode 1. Pushing down the green button switch to testing status, then the green LED on the panel is lighting indicating into testing mode and all 3 channels are active.
Following is the explaining for operation modes for the reference of mode selection:
Mode1: Red LED gradually changes from the darkest to the brightest then to the darkest; this process takes around 60 seconds, then off, after around lasts 75 seconds repeats above process.
Blue LED lights after red LED is lightened around 45 seconds, the brightness changing is same as red LED.
Green LED lights after blue LED is lightened around 45 seconds, the brightness changing is same as red LED.
Mode2: Red LED gradually changes from the darkest to the brightest then to the darkest; this process takes around 60 seconds, then off, after around lasts 60 seconds repeats above process.
Blue LED lights after red LED is lightened around 30 seconds, the brightness changing is same as red LED.
Green LED lights after blue LED is lightened around 30 seconds, the brightness changing is same as red LED.
Mode3: Red LED gradually changes from the darkest to the brightest then to the darkest; this process takes around 30 seconds, then off, after around lasts 15 seconds repeats above process.
Blue LED lights after red LED is lightened around 15 seconds, the brightness changing is same as red LED.
Green LED lights after blue LED is lightened around 15 seconds, the brightness changing is same as red LED.
Mode4: Red LED gradually changes from the darkest to the brightest then to the darkest; this process takes around 5 seconds, then off, after around lasts 2.5 seconds repeats above process.
Blue LED lights after red LED is lightened around 2.5 seconds, the brightness changing is same as red LED.
Green LED lights after blue LED is lightened around 2.5 seconds, the brightness changing is same as red LED.
Mode5: Red LED gradually changes from the darkest to the brightest then to the darkest; this process takes around 30 seconds, then off, after around lasts 60 seconds repeats above process.
Blue LED lights after red LED is off, the brightness changing is same as red LED.
Green LED lights after blue LED is off, the brightness changing is same as red LED.
Mode6: First lighten red LED around 5 seconds then off, followed lighten blue LED around 5 seconds then off, followed lighten green LED 5 seconds then off. Repeat above process.
JS-MJ12RGB-500 controller can be also used for anywhere needs multi-channel LED mixture application. It can be customized as need.
Also available in Red, Green, Amber, Blue, White and RGB
One years manufacturer direct warranty with invoice
Price include a 57 Watt 12DC/4.8A Class 2 indoor power supply
Price also include RGB color controller (JS-MJ12RGB-500) See details below.
Demo shots of Ribbons in action:
