Maxim ICL7665 icl 7665 MAX207 detection 8PIN so dip ic
Model: ICL7665 (Detection IC)
P Voltage Monitor with Dual Over/Undervoltage Detection
Pin-Package: CPA / ACPA / BCPA 8pin Plastic DIP
CSA / ACSA / BCSA 8pin SO
CJA / ACJA / BCJA 8pin CERDIP
Remark: Pls let me know what pin-packing would you need after ordered.
The ICL7665 warns microprocessors ( Ps) of overvoltage and undervoltage conditions. It draws a typical operating current of only 3 A. The trip points and hysteresis of the two voltage detectors are individually programmed via external resistors to any voltage greater than 1.3V. The ICL7665 will operate from any supply voltage in the 1.6V to 16V range, while monitoring voltages from 1.3V to several hundred volts. The Maxim ICL7665A is an improved version with a 2%-accurate VSET1 threshold and guaranteed performance over temperature.
The 3 A quiescent current of the ICL7665 makes it ideal for voltage monitoring in battery-powered systems. In both battery- and line-powered systems, the unique combination of a reference, two comparators, and hysteresis outputs reduces the size and component count of many circuits.
* P Over/Undervoltage Warning
* Dual Comparator with Precision Internal Reference
* 2% Threshold Accuracy (ICL7665A)
* 1.6V to 16V Supply Voltage Range
* On-Board Hysteresis Outputs
* Externally Programmable Trip Points
* Monolithic, Low-Power CMOS Design
High/Low Temperature, Pressure, Voltage Alarms
Power-Fail and Brownout Detection
