Alpha DS1000 dewpoint hygrometer analyzer+DT20 sensor
1 Gently Used, "Alpha Moisture Systems" DS1000 Dewpoint Hygrometer Analyzer+DT20 Sensor/ Transmitter + 2 Alaram relays.
The Model DS1000 utilises proven sensor technology combined with the latest microprocessor based electronics, which has resulted in an analyser which allows the user to quickly and easily determine the dewpoint / moisture content in gases and dry compressed air.
Model DS1000 is a single channel on-line analyser which is primarily designed to monitor the dewpoint and / or control the regeneration cycle of industrial desiccant dryers.
The panel mounting Model DS1000 analyser is 1/8 Din in size, has an IP65 rated front panel and weighs just 350 grams.
Accuracy of 2 C dewpoint is guaranteed over the working range of the sensor, -80 C to +20 C dewpoint, and each unit is supplied with a calibration certificate traceable to the National Physical Laboratory. Standard features include two alarm contacts, isolated 4-20mA retransmission signal, optional RS232 output and 90-240V universal input.
Data sheet: http:// /pdf/DS1000.pdf
