Tv broadcast pa module 12 watts 55-88MHZ
* 55-88MHz Band 1 VHF TV Class A
* 12 watts linear output power at Channel 2**
* 18 watts linear output power at Channel 6**
* 28 volts 3.5A current requirement.
* Input power 0dbm/48dbmv Typical.
* Connects directly to most low power cable TV modulators and exciters.
**Linearity is defined as -40dbc with modulated NTSC color bar signal.
* Each pallet amplifier we sell is designed and tested using HP 8753 vector network analyzers.
* This pallet is optimized for 28 volt operation.
