Fluke PM2811 opt 113 60W programmable dc power supply
Fluke PM2811 - 60W Programmable DC Power Supply
Overvoltage protection: 2 to 32V
Output Voltage: (0.04% of setting + 10 mV)
Output Current: (0.1% of setting + 50 mA)
Over Voltage Protection: (0.5 % of setting + 150 mV)
Output Voltage: (0.016% of setting + 2 mV) /K
Output Current: (0.05% of setting + 2 mA) /K
Output Voltage: 0.04% of setting + 5 mV
Output Current: 0.05% of setting + 10 mA
Over Voltage Protection: 7.5 mV/LSB)
(for any line voltage change within rating)
Voltage: (0.01% of setting + 2 mV)
Current: (0.02% of setting + 2 mA)
(load change 10% to 90% or 90% to 10% full load)
Constant Voltage: (0.01% of setting + 5 mV)
Constant Current: (0.02% of setting + 5 mA)
Negligible for both voltage and current
Constant Voltage pp/rms (40 Hz to 30 MHz): 15 mV/3 mV
Switching Frequency: approx. 20 kHz
* 113 - 60V 5A 60W Rear Output
* Data Sheet (01/99)
* Programming Guide (10/03)
* Reference Manual (06/98)
* Users Guide (06/98)
