> Lincoln dc-400 multi-process welder
Lincoln dc-400 multi-process welder
DC-400 Multi-Process Welding System
Multi-process welding power source from Lincoln Electric.
This heavy-duty, industrial, 3-phase DC-400 multi-process welding power source scores big in MIG, flux-cored, submerged arc, stick, and DC TIG welding. This is a great choice for arc gouging, too. And flexibility doesn't mean complicated-the DC-400s is easy to set up and use. Changeover between processes is as simple as turning a switch with the factory installed multi-process switch. An on-board ammeter and voltmeter make the monitoring of key welding parameters a snap. Inductance and arc force controls allow the operator to efficiently refine the arc for the job at hand.
* Large, conveniently located switch makes it easy to change between CC (stick/TIG/arc gouging), CV (MIG/flux-cored), and CV submerged arc modes
* Arc force control adjusts short circuit current for a soft arc or a forceful driving arc in the CC (stick/TIG) mode
* Arc control adjustment changes pinch effect of the arc to control spatter, fluidity, and bead shape in the MIG/flux-cored mode
* Capable of stick and DC TIG welding and air carbon arc gouging with up to 5/16 in. (8mm) diameter carbon rods
* Solid-state circuitry provides extra-long life for repetitive welding applications
* Outstanding welding performance with a single-range, full-output control potentiometer
* Analog ammeter/voltmeter are standard
* +/-10 percent input line voltage compensation for maintaining weld consistency
* Low-profile case allows for stacking machines up to three high to conserve floor space (stacking not recommended when using undercarriage)
* Fan-cooled for long life expectancy; electronic and thermostatic protection safeguard DC-400 from current overload and excessive temperatures
* Windings and rectifiers protected against moisture and corrosive environments
* 14-pin, MS-style cable connection and terminal strip access for remote control and wire feeder connections and output studs for weld cables.
* Circuit breaker protected on-board power for a wire feeder: 115 V available from the terminal strip, 42 V and 115 V available from the 14-pin connector receptacle
* 115 V AC power on/off switch with pilot light provides added user safety
* Durable powder paint system protects both sides of all painted surfaces to prolong machine's life
* Welder Style Multi-process
* Welder Output 60 500 Amps
27.50 in. 22.25 in. 32.0 in.
We are also throwing in the 4-wheeled cart and a box of goodies as shown above.
For questions, please call (***) 602-1207.
