> 28" x 3HP spdl acer ultima 3VKH cnc vertical mill, prot
28" x 3HP spdl acer ultima 3VKH cnc vertical mill, prot
28" X 3HP Spdl Acer ULTIMA 3VKH CNC VERTICAL MILL, Prot
28" X Axis 3HP Spindle Acer ULTIMA 3VKH CNC VERTICAL MILL, Proto-Trak MX-2 Control,HandWheels,Kurt P
MODEL:ULTIMAX II 3VKH, MFG: 1993
2-AXIS CNC PLUS MANUAL HANDWHEELS
TABLE SIZE....................... 10" x 50"
TABLE TRAVEL (X-AXIS)............ 28.5"
SADDLE TRAVEL (Y-AXIS)........... 14"
QUILL TRAVEL (Z-AXIS)............ 4.5"
KNEE TRAVEL ..................... 16"
RAM TRAVEL ...................... 20"
SPINDLE TAPER.................... R-8
SPINDLE SPEED RANGE.............. 60 - 4200 RPM
MAXIMUM LOAD DISTRIBUTED ........ 500 LBS.
FLOOR AREA (DOORS CLOSED)........ 8' x 7'3"
HEIGHT........................... 6'9"
WEIGHT (WITH CONTROL)............ 3,250 LBS.
- SOUTHWESTERN INDUSTRIES: TRAK MX 2-AXIS CNC CONTROL SYSTEM
WITH SERVO MOTORS, MANUAL DATA INPUT 2-AXIS LINEAR &
CIRCULAR INTERPOLATION, PROGRAM DOWNLOAD, BOLT HOLE
PATTERNS, PART GRAPHICS, DRILL, BORE, MIRROR & MUCH
X & Y BALLSCREWS AND SERVO MOTORS
CONTROL ACTS AS 3-AXIS DRO IN MANUAL MODE
TRANSITION FROM TWO AXIS CNC TO MANUAL MACHINING
PERFECT FOR A TOOLROOM OR PROTO TYPE WORK
INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE.
