> Hp agilent 355C dc-1GHZ 1000MHZ 1DB vhf step attenuator
Hp agilent 355C dc-1GHZ 1000MHZ 1DB vhf step attenuator
HP AGILENT 355C DC-1GHz 1000MHz 1DB VHF STEP ATTENUATOR
SearchBy9 - 14134 | Location: A85 | By: MATTY | Tester: CARL | Quan: 1 | List: 1 | Duplicate? False | Plan: D
Standard Relist: True | Size: 0x0x0 Weight: 5 | MGR: SELF MANAGED LISTING (No MGR) | Start: $0.00 | BIN: $74.99 | Type: Fixed Price
Sales: | Business & Industrial > Electrical & Test Equipment > Test Equipment > Attenuators
HP AGILENT 355C VHF STEP ATTENUATOR
The 355C dc to 1000 MHz manual step attenuator provides precision step attenuation in 1 dB steps from 0 to 12 dB. Attenuator sections are inserted and removed by cam-actuated microswitches which keep lead lengths short. This design minimizes stray capacitances and inductances, and keeps phase shift to a minimum. The Agilent 355C is a compact and rugged unit in which the component parts are rigidly positioned and well-shielded so that neither stray pickup nor signal leakage is a problem. It may be connected with the 355D in series to provide precision attenuation in 1 dB steps from 0 to 132 dB. Either terminal may be connected as input or output.
# Frequency Range: dc to 1 GHz
# Attenuation Range: 0 to 12 dB, 1 dB steps
# Insertion Loss at 0 dB: 0.2 dB + 2.3 dB/GHz
# Maximum SWR: 1.2 to 250 MHz, 1.3 to 500 MHz, 1.5 to 1 GHz
# Repeatability Life: 0.03 dB maximum, 0.5 million cycles per section
# Maximum RF Input Power: 0.5 W (average), 350 W (peak)
# Connector Type: BNC female, optional Type-N female and TNC female
