Hp agilent 16910A - logic analysis module
HP Agilent 16910A - 102Ch 4 GHz Timing/250 MHz State Logic Analysis Module
Timing Analysis (Asynchronous Sampling)
* 4 GHz (250 ps) timing zoom with 64 K memory
* 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
* 500 MHz transitional timing
State Analysis (Synchronous Sampling)
* State clock rates up to 450 MHz
* Data rates: up to 500 Mb/s
* Automated threshold/sample position setup for accurate measurements on high-speed buses
* Simultaneous eye diagrams on all channels identify problem signals quickly
Configuration Considerations
* 102-channels per module, combine up to 5 modules for 510 channels
* Selectable memory depths: 1 M, 4 M, 16 M, 32 M
* Compatible with 40-pin logic analyzer probes.
* Compatible with 16900 Series modular logic analyzers
* Comprehensive single-ended signal support, threshold is adjustable from -5 V to 5 V (10 mV increments)
* 016 - Increase acquisition memory depth to 16M
* 500 - Increase maximum state speed to 500 Mb/s.
* 16900 Series Installation Guide (11/07)
* Data Sheet (04/05)
* Data Sheet (11/06)
