New wiremaster xr-2 - lan cable test set w/ tracer tone
New WireMaster XR-2 - LAN Cable Test Set w/ Tracer Tone
Image of New WireMaster XR-2 - LAN Cable Test Set w/ Tracer Tone
* Verifies point-to-point wiring of twisted pair LAN cables, telephone cables, and other types of cables that use RJ-45& RJ-11 connectors
* New "Local Mode" allows for testing of patch cables
* Tests LAN Crossover & Telephone patch cables
* Checks continuity in cable conductors
* Generates 2 distinct warble tones usable for cable tracing
* Checks "straight-through", "reverse wired", & "crossover" patch cables
* 8 LED's identify the source and destination of each conductor
* Direct connection of 6 pin RJ-11 or 8-pin RJ-45 cables
* Allows remote testing of long cable runs up to 1000 feet
* RJ-11 4 conductor or 6 conductor test
* Forward or Reverse sequencing on Transmitter
