Detroit diesel engines v-71 operators service manual
Detroit Diesel Engines V-71 Operators Service Manual
Description - principles of operation, general description, model description, general specifications, engine model and serial number designation, built-in parts book, cross section views of engine, three quarter engine views.
Engine Equipment - Instrument panel, instruments and controls, engine protective systems, starting system, governors, transmissions.
Lubrication and Preventive Maintenance - Lubrication and preventive maintenance, fuel oil specifications, lubricating oil specifications, engine coolant.
Engine Tune-Up Procedures - Section 6: Engine tune-up procedures, exhaust valve clearance adjustments, timing fuel injector, limiting speed mechanical governor adjustment for the following ( 6, 8, 12V and 16V). Limited speed mechanical governor (Fast Idle Cylinder), Variable Speed Mechanical Governor Adjustment (6, 8, 12V and 16V). Supplementary Governing Device Adjustment. Variable Speed Hydraulic Governor Adjustment (6, 8, 12V, and 16V). Limiting Speed Hydraulic Governor Adjustment (16V). Hydraulic Governor (EG_B Electric) Adjustment (6, 8, and 12V). Mechanical Output Shaft Governor and Linkage Adjustment. Hydraulic Output Shaft Governor and Linkage Adjustment.
