Hp agilent 66104A dc power module refurbished
HP Agilent 66104A DC Power Module Refurbished
The 66104A DC Power Module simplifies test-system assembly, cabling programming, debugging, and operation. It is ideal for ATE and production test environments, where it can supply bias power and stimulus to subassemblies and final products. The 66000A 7-in high (4-EIA units) mainframe (not included) can accommodate up to eight dc power modules. The module is rated 0 to 60 V @ 2.5 A. Power output is 150 watts.
- Output voltage: 0 to 60 V
- Output current: 0 to 2.5 A
* Programming Accuracy at 25 C 5 C
* Ripple & Noise (20 Hz to 20 MHz)
- Constant Voltage rms: 9 mV
- Constant Current rms: 1 mA
* Readback Accuracy (via GPIB or keyboard display at 25 C 5 C)
