> May tool company model 42V 3/4 ring & circle shear
May tool company model 42V 3/4 ring & circle shear
MAY TOOL COMPANY MODEL 42V 3/4 RING & CIRCLE SHEAR
Capacity......................16 ga.(Mild), 18 ga.(Stainless)
Circle Diameter...............3-1/2" - 42"
Max Flange Depth..............1/2"
Depth of Head Throat..........10"
Depth of Tail Throat..........30"
Gear Ratio....................5 - 1
Cutting RPM...................350
Main Motor....................3/4 HP, 110v, 1ph
Weight........................400 lbs.
3/4 HP Variable Speed Motor & Control
