New trivec - uhf satcom antenna - portable miltary yagi
Trivec - NEW UHF Satcom Antenna - Portable Miltary Yagi
Up for sale is a NEW Trivec AV-2055 Portable UHF Stacom antenna. This antenna is extremely portable with a weight under 5 pounds and a unique folding assembly. This unit is brand NEW. It is in great shape except for the front clasps on the strap which are broken. That is a small defect in an extremely sophisticated and rugged military antenna.
The AV-2055-3 antenna is a 3 element YAGI with 2 sets of removable directors. The antenna provides 10.9 dB of gain and a frequency range between 240-318 MHz.
The AV 2055-3 is lightweight and housed in a compact carrying case (115mm diameter x 229 mm long). The antenna can be quickly deployed in less than a minute and the tripod base allows stable ground mounting.
Polarization: Right Hand Circular
Finish: Black Anodized / epoxy
Deployment Time: Less than 1 minute.
Operating Temperature: -32 to 71 Celsius
Antenna Length from outer ring: 788 mm ref
Outer Ring Diameter: 622 mm ref
Listed for M.A. by A.A. - Located at: EB2-B-4
