Trimble arcsecond vulcan gps spatial laser transmitter
This is a Trimble/Arcsecond Vulcan II TX Laser Transmitter / 3D Spatial Digitizer. These units are used for various purposes including 3D Spatial Digitation, Indoor GPS (iGPS) implementations, automation & manufacturing, surveying, etc. They are normally parts of larger digitation kits such as the Trimble Vulcan Spatial measurement system or the Arcsecond Constellation 3Di Indoor GPS system.
The unit operates off of 8 standard D-Cell batteries; it also has a jack for an AC Adapter/charger although I do not have a charger for this unit.
When powered on; the units level and adjust. Various LED's light up during the startup sequence. Once finished with the startup sequence, the top laser transmitter then begins to rotate at a high velocity. The unit also has a laser-plumb on the bottom; this is used to mount the unit on a tripod over a specified target (such as a regular plumb-bob). The laser light is bright & vivid on all of the units.
Physical condition is good; there are some scuffs and scratches from normal usage but absolutely no structural damage or any cracks at all. The battery compartments are clean as well. I do not know if these units need to be calibrated and I do not have any calibration history on them.
Unit was manufactured in 2001.
These units are branded by: Trimble, Spectra Precision, Spectra Physics, ArcSecond
* Arcsecond Constellation 3Di Brochure - Indoor GPS.
This description was formatted by 'richieswares'. Please do not copy the above description text without my permission..
The unique modular nature of Constellation 3Di provides unmatched flexibility in configuration and expandability to meet the needs of a wide variety of applications. The system can accommodate an unlimited number of sensors that can be added or subtracted from the network at any time. Likewise, the network can be expanded and the system accuracy improved through the addition of transmitters.
