Ideal 61-768 600A ac/dc clamp meter /tightsight display
* 600A DC current measurements
* Voltage-presence warning on all functions
* Tapered jaws with hook tip
* Includes leads, alligator clip and case
3-3/4 digit LCD with 4000 counts for both displays
Green illumination with auto-off after 4.5 minutes
41 segment LCD with measurements of 20 times per second
Automatic, positive implied, negative (-) polarity indication.
Samples 2 times per second, nominal.
Approximately after 30 minutes of non-use.
400 hours continuous with Alkaline (61-764)
200 hours continuous with Alkaline (61-766)
150 hours continuous with Alkaline (61-768)
The " " is displayed when battery voltage drops below operating level.
(1) 9V battery (NEDA 1604, JIS 006P, IEC 6F22)
Includes an isolated battery compartment.
Stated accuracy at 23 C 5 C, <75% R.H.
0.1 x (specified accuracy) per C,
32 F to 122 F (0 C to 50 C) at < 70% R.H.
-4 F to 140 F (-20 C to 60 C) at < 80% R.H. with battery removed from meter
Accepts a 1.42" (36mm) conductor
8.7 H x 3.1 W x 1.8 D (222mmH x 80mmW x 45.5mmD)
12.3 oz (350g) including battery
Carrying Case, Test Leads with alligator clip, (1) 9V battery, operating instructions.
Complies with EN 61010-1, EN 61010-2-032, UL 61010-1, IEC 61010-2-032, IEC61010-031 specifications, Cat IV-600V/Cat III-1000V.
Instrument has been evaluated and complies with insulation category II (overvoltage category II). Pollution degree 2 in accordance with IEC-644. Indoor use.
61-764 model is averaging sensing, rms calibrated, 61-766, 61-768 models are true rms sensing.
Accuracy is specified as +/-(a percentage of the reading + a fixed amount) at 23 C 5 C (73.4 F 9 F), less than 75% relative humidity.
0.1 times the applicable accuracy specification per degree C from 0 C to 18 C and 28 C to 50 C (32 F to 64 F and 82 F to 122 F)
