1992 matsuura ra-iif 5 axis cnc vmc w/pallet shuttle
1992 MATSUURA RA-IIF 5 AXIS CNC VMC w/PALLET SHUTTLE
MATSUURA RA-IIF DUAL PALLET 5 AXIS VERTICAL MACHINING CENTER
CONTROL......................... YASNAC I80
PALLET LENGTH................... 23.6"
PALLET WIDTH.................... 14.9"
MAX. PALLET LOAD................ 550 LBS.
NO. OF PALLETS.................. 2
TRAVELS: X-CROSS/LONG........... 23.62"
Y-SADDLE............... 16.14"
RAPID TRAVERSE.................. 945 IPM (X,Y) 708 IPM (Z)
FEEDRATE........................ 393.7"
SPINDLE: SPEED MIN RPM.......... 30 RPM
MAX. RPM........................ 8,000 RPM
MOTOR HP........................ 20 HP
TAPER........................... BT-40
MAX. TOOL DIAMETER.............. 3.77" / 6.8" ADJ. EMPTY
MAX. TOOL LENGTH................ 11.8"
MAX. TOOL WEIGHT................ 22 LBS.
TOOL CHANGE TIME................ 2 SEC. (TOOL TO TOOL)
PALLET CHANGE TIME.............. 9 SEC.
DISTANCE FROM FLOOR TO TABLE.... 40"
MACHINE FLOOR SPACE............. 3469W x 3936D
MACHINE HEIGHT.................. 112"
MACHINE WEIGHT.................. 4500 kg
NIKKEN 2 AXIS TRUNION TYPE ROTARY TABLE
HIGH PRESSURE COOLANT THRU SPINDLE (1000 PSI)
MACHINE RUNS GREAT..INSPECT UNDER POWER IN NJ.
