New 10 circuit board barrier blocks terminal strips 15A
Click here to see our other PCB terminal blocks
Overall height (excluding pins): .590"
Pin spacing: .375" (3/8") OC (on centers)
Pin dimensions: .052" x .032" x .207" long
Screws: PhilSlot (phillips head or flat slotted)
The part number CBD202204 breaks down as follows:
Series A2000, LP2000 & CB2000 Single Row Terminal Blocks
Center Spacing: .375 or 3/8 (9.52 mm)
Screw Size: #6-32 zinc plated philslot Torque Rating: 9 in-lb. max.
Base: Standoffs standard for easy flux washing
Distance Between Barriers: .32 (8.1 mm)
Recommended PCB Hole Diameter: .076 (1.93 mm); .062 (1.59 mm) on .045 terminals.
Operating Temperature: 105F (221F) max., -40C (-40F) min.
Molded Material: Black, UL Rated 94VO Thermoplastic
Breakdown Voltage: 3400V rms (A2 & LP2); 4100V rms (CB2).
Approvals: UL E62622; CSA LR15364; IEC Compliance; CE Certified
*20A Rating achieved with a #10 copper wire crimped to a ring terminal; 15 Rating without ring terminal.
(12 to 14) lots: Five pounds
