Hp agilent 180TR oscilloscope mainframe
HP Agilent 180TR Oscilloscope Mainframe
Powers up, operational. Not fully tested.
The Agilent HP 180TR Rack Mount Normal Persistence Display Mainframe employs the versatility and ease-of-use that are still required in today's applications. Designed to use a wide range of plug-ins (sold separately), the 180TR is the ideal mainframe for use as an Oscilloscope or Spectrum Analyzer System Mainframe. The 180 "T" series displays are recommended for use with the 8755B. They provide zero offset recorder outputs, and both positive and negative 5-volt retrace blanking inputs.
The 182T and 180TR are directly compatible with the 8750A Storage-Normalizer. As a result of the 8705A compatibility, the 182T and 180TR cannot be used with time-domain plug-ins.
* 8 x 10 division internal graticule with 1 div = 1 cm
* medium persistence P39 phosphor
