Mastech HY3005F-3 variable triple power supply 30V 5A
MASTECH HY3005F-3 VARIABLE TRIPLE POWER SUPPLY 30V 5A
For sale is a brand new professional DC regulated power supply from Mastech, Model number HY3005F-3. This high quality linear power supply has three outputs: two outputs are continuously adjustable at 0-30V DC and 0-5A, and the third output is fixed at 5V DC and 3A. What's more, the two outputs can be used either in independent, series or parallel mode, providing either two independent outputs, or one output with twice the voltage or twice the current output, up to 60V or 10A. The unit comes with 4 color LED displays, providing accurate and clearly visible readout for the voltage and current value. LED displays are new trend in instrumentation, because they are more durable and easily viable even in dark environment. This unit has toggle switch at the back that allows you to operate it in 110V AC or 220V AC. retails well over $400. Please email us with any questions, our hard-working staff will answer every email in no time!
* Easy control for both current and voltage outputs
* Dual adjustable outputs: 0-30V and 0-5A
* Input voltage: 110V AC and 220V AC switchable
* Line regulation: CV <= 0.01% + 2 mV, CC <= 0.2% + 2 mA>
* Load Regulation: CV <= 0.01% + 3mV, CC <= 0.2% + 3 mA
* Ripple noise: CV <= 0.5 mV RMS, CC <= 3 mA RMS
* Protection: constant current and short-circuit protection
* Display reading accuracy: +/-1% for voltage and +/-2% for current
* Environment: 0-40C, relative humidity < 90%
