New ercolina SB48 super bender, rotary draw tube bender
NEW ERCOLINA SB48 Super Bender, Rotary Draw Tube Bender
NEW ERCOLINA SB48P Super Bender, Rotary Draw Tube Bender, 110 Volt
2" diameter x 0.120" wall (Electro Weld Seam Mild Steel Tube)
Pipe up to 1-1/2" schedule 40 (A53 Mild Steel)
Square tube to 1-1/2" X 0.120 wall (All based on mild steel material).
Bends to 90 degrees in 7 seconds
Patented tooling system with multiple radii available.
Induction motor with electromagnetic brake for greater accuracy
Patented swing away counter bending die vise
Programmable control with display
Operator friendly microprocessor with soft touch keyboard memorizes thirty individual bend programs with nine bends per program.
Remote foot pedal standard for hands free operation
Programmable material spring back settings with display ensures bend accuracy for a wide variety of material
Hex mounted formers for rapid tool changes
Maximum Centerline Radius: 8-7/8"
Wheels and handle built into base cabinet for easy movement to work area
Accepts Ercolina's two axis A40/P Positioner table for multiple bends in two planes.
OPTIONAL PIPE KIT (ADDITIONAL COST, CALL FOR PRICING)
