New shop fox W1702 - 30-1/2" x 28-1/4" 3 hp shaper
Shop Fox W1702 - 30-1/2" x 28-1/4" 3 HP Shaper NEW
This full capacity 3 HP Shaper will handle the smallest profile cutters all the way up to the largest panel cutters with its three spindle sizes, 3" spindle travel and 5-1/2" maximum spindle opening. Two reversible speeds also provide the greatest flexibility for arranging cutters of all sizes. So, no matter what the shaping application is, whether it's simple edge profiling or making door stiles, rails and panels, this is the right machine for the job.
Large handwheel elevates the spindle for precise control and spindle lock knob ensures consistent results
Heavy cast iron, independently adjustable split fence allows full edge profiling
Starting pins allow irregular shaping
Spindle openings: 1-3/8", 2-3/4", 4" & 5-1/2"
Magnetic switch with thermal overload protects the operator and machine
Interchangeable spindles are easily installed or removed
Removable table inserts provide work support close to the cutter
Motor: 3 HP, 220V, single-phase with reversing switch
Large precision ground cast iron table
Table size: 30-1/2" deep x 28-1/4" wide
Magnetic switch with thermal overload protector
Shielded and lubricated ball bearings
Spindle speeds: 7,000 & 10,000 RPM
