Nos globe 33A613-750 115V ac 1 phase 60HZ pn 33A613-750
25140 33A613-750 GLOBE MOTORS INC
AAJU OVERALL LENGTH 3.688 INCHES
AAJV OVERALL WIDTH 1.250 INCHES
ABWV SHAFT DIAMETER 0.2494 INCHES NOMINAL SINGLE END
AKCT SHAFT ROTATION DIRECTION CLOCKWISE OR COUNTERCLOCKWISE SINGLE END
ANPZ INCLOSURE FEATURE GENERAL PURPOSE
AXGY MOUNTING METHOD CLAMP RING
AXHR MOUNTING FACILITY TYPE AND QUANTITY 4 THREADED HOLE
BFLY GEARED HEAD OUTPUT SHAFT ALIGNMENT POSITION INLINE W/ROTOR AXIS SINGLE END
BFMF COOLING METHOD AMBIENT AIR
CWCS LENGTH OF SHAFT FROM HOUSING 0.500 INCHES SINGLE END
CWGQ CONNECTION TYPE AND VOLTAGE RATING IN VOLTS 115.0 LINE TO NEUTRAL SINGLE INPUT
CWHK GEARED HEAD OUTPUT SHAFT SPEED RATING 4.500 SINGLE REVOLUTIONS PER MINUTE SINGLE END
CWHZ SHAFT END CHARACTERISTIC A1 SINGLE STYLE SINGLE END
FREQ FREQUENCY IN HERTZ 60.0 INPUT
SR-5 DESIGN CONTROL REFERENCE 33A613-750
TTQY TERMINAL TYPE AND QUANTITY 4 WIRE LEAD
FZA 496L SPACETRACT NETTED SYSTEM OF SPACE SENSORS
