Leisegang 1H3 medical laser aiming apparatus
Leisegang 1H3 medical laser aiming apparatus
This unit is a component from a medical laser system. It was the component used to aim the laser onto its target; it has a pair of eyepieces for a binocular magnifier (magnification is not indicated), a built-in illumination light source with a knob on the side and a cable ending in a round male two-pin connector, a lever that controls a metal shutter over the laser aperture, and a small joystick that appears to be used for fine adjustment of aim. There are two rotating handles for adjusting focus and elevation. The unit doesn't include a laser; when it was originally mounted on the full medical laser system a laser was sent up the hollow core of the support rod to be aimed by this component. You'll need to mount it in a similar manner to use it for this purpose.
The optics are clear and all of the positioning adjustment mechanisms appear to function correctly. There's a bulb in the light source but it hasn't been tested.
One Leisegang 1H3 medical laser aiming apparatus
