> Grove RT635C service / maintenance manual package set
Grove RT635C service / maintenance manual package set
GROVE Crane Service Maintenance Manual for Model RT635C
This manual consists of two seperate parts: the Basic Service Manual and the Service Maintenance Packages. The Published Date is September 1993.
This Manual is Covering the Following:
Chapter One: (General Description and Maintenance)
General Description - Description, List of Specifications.
General Maintenance - Maintenance.
Chapter Two (Detailed Description, Operation, and Maintenance)
Section 2: Engine - engine, fuel system, air intake system, water cooling system.
Section 3: Drive Train - drive train, transmission/torque converter, transmission control valve.
Section 4: Axles - axles, wheels and tires.
Section 5: Steering Systems - steering systems, steering pump, front steering control valve, rear steering control valve, steer cylinders, flow divider valve.
Section 6: Rear Axle Oscillation Lockout System - rear axle oscillation system.
Section 7: Brake System - brake system, service brakes, hydraulic brake autuation unit, hydraulic spring brake actuator, parking/emergency brake, park brake valve, pressure relief valve.
Section 8: Hydraulic System - hydraulic system, supply pressure and return circuit, hydraulic pumps, hydraulic pump disconnect, heater pump, valves, cylinders.
Section 9: Swing System - swing system, swing motor, swing gearbox, swing brake, swing bearing, swing power brake valve, pressure relief valve, swing lock.
Section 10: Boom - boom, boom extension and retraction cable, telescope circuit, lift circuit, swingaway boom extension, hook block.
Section 11: Hoists - hoists, hoist to boom alignment, vane type motors, idler drum and cable follower, hoist drum rotation indicator, hoist control valves.
Section 12: Outriggers - Outrigger circuit, outrigger beam, extension cylinder, stabilizer cylinder, intergrated outrigger valves, solenoid valve stack, pilot operated check valve.
Section 13: Swivels - swivels, 15 Port hydraulic swivel, electrical swivel.
Chapter Three (Optional Equipment)
Section 1: Miscellaneous Option Equipment
Section 2: Emergency Steering System - emergency steering system, emergency steer pump.
Section 3: Front Mounted Tow Winch - front mounted tow winch, electrically actuated control valve.
Section 4: High Speed Glide System
Section 6: Cab Heating And Air Conditioning System - cab heating and air conditioning system, hydraulic heater, hydraulic air conditioner, hydraulic heater and air conditioner, propane heater.
Service and Maintenance Package Includes:
Air intake system, water cooling system.
Transmission/torque converter, transmission control valve.
Rockwell axle, nospin differential, single reduction differential carriers.
Steering control valve, emergency steer pump.
Hydraulic spring brake actuator, hydraulic brake actuation unit, parking/emergency brake, rockwell brakes.
Hydraulic pump (torque converter driven), integrated outrigger valve, outrigger solenoid valves (axle lockout valve), pilot operated directional control valve, treadle valve, throttle control cylinder, joystick control valve, pilot operated check valve, pressure relief valve, hydraulic pump (engine driven), electrically actuated control valve, hydraulic pump disconnect.
Swing motor, swing gearbox swing brake.
Hydraulic swivel, electrical swivel.
