Walker turner 1100 radial drill operator/part manual
This is a reproduction, not a photocopy, of an original Walker Turner 1100 Series Radial Drill Instruction and Parts Manual, models RD1175J and RD1170. I combine two manuals, because they were so similar and had some of the same information. The only real difference between the two machines is that one has a two pulley drive system and the other one has a four pulley drive system for more speed changes.
This manual contains information on general set up, removing the chuck, removing the spindle and quill assembly, lubrication, maintenance, and controls as well as a complete parts lists and diagrams. I also included 2 pages about these machines from a Walker Turner catalog.
Walker Turner made good machines, and was bought out by Rockwell/Delta. Many of these machines are still in working condition today, but these manuals are hard to come by in any kind of condition, because of they were printed on cheaper paper. So it was difficult for me to find these manuals and clean them up to acceptable standards.
