> 18" x 120" mazak engine lathe, mdl. 18120, s/n 26817
18" x 120" mazak engine lathe, mdl. 18120, s/n 26817
ONE Preowned MAZAK Engine Lathe
CAPACITY .. .. 18 / 27 x 120
SWING OVER BED . 18"
SWING OVER CROSS SLIDE .. 10"
SWING IN GAP 27"
DISTANCE BETWEEN CENTERS ... 120"
SPINDLE SPEEDS (12) .. 25- 1,500 RPM
SPINDLE NOSE ... D1- 8
HOLE THRU SPINDLE 3 1/8"
INCH (40) ... 4- 56 TPI
METRIC (23) . 0.5- 7MM
FEEDS (40) 0.0027"- 0.037"
CROSS SLIDE TRAVEL .. 11"
TAILSTOCK QUILL TRAVEL . 5"
TAILSTOCK QUILL TAPER #4 MT
DIMENSIONS (L X D X H) .. 177" X 46" X 54"
ACU-RITE III 2 AXIS DIGITAL READOUT SYSTEM
