Oz~walker turner 1100 radial drill operator/part manual
This is a reproduction, not a photocopy, of an original Walker Turner 1100 Series Radial Drill Instruction and Parts Manual, models RD1175J and RD1170. I combine two manuals, because they were so similar and had some of the same information. The only real difference between the two machines is that one has a two pulley drive system and the other one has a four pulley drive system for more speed changes.
This manual contains information on general set up, removing the chuck, removing the spindle and quill assembly, lubrication, maintenance, and controls as well as a complete parts lists and diagrams. I also included 2 pages about these machines from a Walker Turner catalog.
