> AWG7102 AWG7101 AWG7121B AWG7121AWG7122B AWG7122
AWG7102 AWG7101 AWG7121B AWG7121AWG7122B AWG7122
tek warranty expires feb. 2011
Opt. 01 Waveform Length Expansion (from 32 M to 64 M)
* 10 GS/s (20 GS/s) and 5 GS/s Models
* 1 or 2 Arbitrary Waveform Outputs
* Accurate Timing with only 20 psp-p Total Jitter (at 10-12 BER, Typical)
* 45 ps Tr/Tf (20% to 80%)
* 100 ps Range (1 ps Resolution) Interchannel Skew Control
* 2 or 4 Variable-level Marker Outputs
* Accurate Timing with only 30 psp-p Total Jitter (at 10-12 BER, Typical)
* Up to 300 ps Range (1 ps Resolution) Delay Control
* Vertical Resolution up to 10 bit Available: 10 bits (No Marker Output) or 8 bits (with Two Marker Outputs)
* Up to 64 M (64,800,000) Point Record Length Provides Longer Data Streams
* Down to 100 fs Resolution Edge Timing Shift Control
* Sequencing Creates Infinite Waveform Loops, Jumps, and Conditional Branches
* Real-time Sequencing Creates Infinite Waveform Loops, Jumps, and Conditional Branches
* Intuitive User Interface Shortens Test Time
* Integrated PC Supports Network Integration and Provides a Built-in DVD, Removable Hard Drive, LAN, and USB Ports
* Disk Drive (Magnetic/Optical) Read/Write:
* Up to 5 Gb/s Data Rate (2 Points/Cell) or 50 ps Timing Resolution
* Telecom/Data Communications:
* Up to 10 Gb/s Data Rate (Binary, Pre/De-emphasis, and Multilevel Logic)
* Up to 5 GHz (4 Waveform Points/Cycle) Arbitrary RF/IF and Wide-bandwidth Modulation I and Q Baseband Signals
* Mixed-signal Design and Test:
* 2-channel Analog plus 4-channel Marker Outputs
* High-speed, Low-jitter Data/Pulse and Clock Source
* Real-world, Ideal, or Distorted Signal Generation Including All the Glitches, Anomalies, and Impairments
* Enhanced/Corrupted Playback of DSO Captured Signals
* Waveform Vectors Imported from Third-party Tools such as MATLAB, MathCAD, Excel, and Others
