Landis cnc universal cylindrical grinder 2-axis 1R
Landis CNC Universal Cylindrical Grinder 2-Axis 1R
http:// /watch?v=X1p01rf6LaI
Landis 2-Axis CNC Universal Cylindrical Grinder
This grinder was retrofitted with a GE/Fanuc 18-GCA CNC
control in 1995 and was rebuilt in 2002. It was recently
removed from service from a local aerospace company
Grinding Capacity: 10" x 20"
Grinding Wheel Size: 12" x 3" Width
Grinding Wheel Swivels: +/- 90 Degees
Grinding Wheel Speeds: 2000 & 2530 RPM
Workhead Speeds: 0 - 600 RPM
Axis Feed Rate Increments: .0001" - .1"
Axis Feed Rates, Variable: 0 - 150 IPM
GE/Fanuc 18-GCA 2-Axis CNC Control Package
Marposs P5 In-Process Gauging System
Automatic Lube System with Fault Alarm
Refrigerated Electrical Cabinet
3 HP Grinding Wheel Motor 230/460/3/60
Approximate Net Weight: 5,500 Lbs.
