Diy avr jtagice emulator debugger atmel programmer ice
DIY AVR JTAGICE Emulator Debugger ATMEL Programmer ICE
DIY Version, Compatible with original JTAGICE 1
1) AVR Studio 4.0 above, WINAVR (GCC) compatible
2) Supports all AVR Devices with JTAG Interface
3) Emulates all Digital and Analog On-Chip Functions
4) RS232 or USB interface to PC for Programming and Control
5) Regulated Power supply for 9 - 15VDC
JTagICE Supports Devices list:
ATmega16,ATmega16L,ATmega32,ATmega32L,ATmega64,ATmega64L,
ATmega128,ATmega128L,ATmega162,ATmega162V,
ATmega169,ATmega169V,ATmega169L,ATmega323,ATmega323L
ATmega8,ATmega16,ATmega32,ATmega48,ATmega48P,ATmega64,
ATmega88,ATmega88P,ATmega103,ATmega128,ATmega1280,
ATmega1281,ATmega1284P,ATmega16HVA,ATmega161,ATmega162,
ATmega163,ATmeg164P,ATmega165,ATmega165P,ATmega168,ATmega168P,
ATmega169,ATmega169P,ATmega323,ATmega324P,ATmega325,ATmega325P,
ATmega328P,ATmega329,ATmega329P,ATmega644P,ATmega645, ATmega649,
ATmega2560,ATmega2561,ATmega3250,ATmega3250P,ATmega3290,ATmega3290P,
ATmega6450,ATmega6490,ATmega8515,ATmega8535, ATmega32C1,ATmega32M1,
ATtiny12,ATtiny13,ATtiny15,ATtiny22,ATtiny2313,ATtiny24,ATtiny25,
ATtiny26,ATtiny261,ATtiny43U,ATtiny44,ATtiny45, ATtiny461,ATtiny84,
ATtiny85,ATtiny861,ATtiny88,ATtiny167 AT 90 AT90S1200,AT90S2313,
AT90S/LS2323,AT90S/LS2343,AT90S/LS2333,AT90S4414,AT90S/LS4433,
AT90S/LS4434,AT90S8515,AT90S/LS8535
AT86RF401,AT89S51,AT89S52,AT90CAN32,AT90CAN64,AT90CAN128,
AT90PWM2,AT90PWM2B,AT90PWM3,AT90PWM3B, AT90USB82,AT90USB162,
AT90USB646,AT90USB647,AT90USB1286,AT90USB1287
AVR studio recognize it as JTAGICE, fully compatible with original.
The JTAGICE also support devices with debugWIRE Interface. debugWIRE enables on-chip debug of AVR microcontrollers in small pin count packages, using only a single wire for the debug interface.
The JTAGICE is supported by the AVR32 Studio.
