16" swg 40" cc birmingham ycl-1640 package deal engine
16" Swg 40" cc Birmingham YCL-1640 Package Deal ENGINE
16" Swing 40" Centers Birmingham YCL-1640 Package Deal ENGINE LATHE, 7.5 HP, 12 Speed, 2-9/32" Spind
Model: YCL-1640 w/Removable Gap Block
lower 48 states, taper attachment (installed), Uniq 2 Axis
This high speed precision lathe comes with many features including
one-piece cast iron body, no change gears required, 60 kinds of
inch threads from 112 -2 TPI, fine grain high tensile cast iron bed.
Main spindle, bedways, gears and all shafts are hardened and precision
ground. A valuable addition to any machine shop.
Effective Length in Gap: 9-1/2"
Diameter of Spindle Thru Bore: 2.28"
Spindle Speeds: 25 - 2,000 RPM, 12 Steps
Metric Threads: 0.1 - 7 mm, 34 Kinds
Inch Threads: 4 - 112 - TPI, 60 Kinds
Diameter of Tailstock Quill: 2.3"
Taper of Tailstock Quill Center: MT#4
Max. Travel of Tailstock Quill: 4.8"
Brand Name Digital Readouts - Newall C80 or Sargon Gold
5-C Hand Lever Type Collet Closer "JFK" USA
