Omega fl-515 air or water in-line 1" flowmeter
OMEGA FL-515 AIR OR WATER IN-LINE 1" FLOWMETER
Internal Wetted Parts : 316 SS
Liquid Service : 200 psig @ 21 C (70 F)
Gas Service : 100 psig @ 21 C (70 F)
Maximum Temperature : 66 C (150 F) @ 25 psig
Dimensions: 177.8 mm (7") long 50.8 mm (2") Dia.
scales : 1.5-15 gpm, 15-135 scfm and metric equivalents
