> New shop fox W1773 15 hp 3-phase 37" drum sander
New shop fox W1773 15 hp 3-phase 37" drum sander
Shop Fox W1773 15 HP 3-Phase 37" Drum Sander NEW
W1773 - SHOP FOX 15 HP 3-Phase 37" Drum Sander
Variable speed conveyor control box
Control panel with Amp load meter
Sanding drums: 2, steel/rubber
Designed for production shops, this 37" sander has what it takes to get those big jobs done - fast. Sand panels and boards up to 4" thick and 36-1/2" wide with the dual 6" sanding drums. Feed speed is adjustable from 6 to 18 FPM. The variable speed knob and amp meter make it easy to monitor workpiece load. Other great features: a hinged hood, an emergency stop bar, pedestal-mounted controls, four 4" dust ports, and a 15 HP, 220V/440V 3-phase motor.
Industrial rubber conveyor belt (similar to wide belt sander belts)
State-of-the-art computer balanced drums
Sanding drum motor: 15 HP, 220V/440V*, 3-phase, TEFC, 1725 RPM
Minimum board thickness: 1/16"
Surface speed of drums: 2800 FPM
Conveyor feed rate: Variable, 6 - 18 FPM
Overall size: 49"H x 68"W x 50-1/2"D
