Remote control RCI230-sr pneumatic actuator 150 psi
Remote Control RCI230-SR Pneumatic Actuator 150 PSI NR
Remote Control RCI 230-SR Series Pneumatic Actuator
The Remote Control RCI 230-SR Series Pneumatic Actuator features a modern scotch yoke mechanism, which allows us to produce an actuator with high starting and ending torques in a very compact package. The RCI 200 Series offers great flexibility. Our spring return actuator features a spring module with the spring(s) safely contained and are epoxy powder coated for maximum corrossion resistance. Our pistons are guided in two places with reinforced Teflon bearings which insure positive alignment and long sea life.
* Body: Extruded Aluminum, Anodized finish
* Spring Housings, End Caps: Cast Aluminum, Anodized Finish
* Pistons: Anodized Aluminum
* Drive Shaft: Stainless Steel
* Fasteners: Stainless Steel
* Pressure Rating: 150 PSI Continuous
* Temperature Range: -200 F to +1750 F
* Temperature Seals, Low Pressure Hydraulic Service, Water Hydraulic Service, Fast Opening/Closing Speed.
* Operating Medium: Compressed Air or Inert Gas
* Mounting Dimensions: ISO 5211 Standard
* SACS Distributors will determine that the item is not as advertised and that all part/accessories have been returned. At our sole discretion, we will issue a refund or exchange the unit for an identical item.
