Nice swi 10" x 50" 3-axis cnc vertical milling machine
NICE! SWI 10" x 50" 3-AXIS CNC VERTICAL MILLING MACHINE
Made by Southwestern Industries.This is a 3-Axis CNC Vertical Milling Machine in working condition.Model #: Trak DPMSerial #: 96-2308The TRAK DPM is the Dual Purpose Mill, to be used both as a Two-Axis and as a sophisticated Three-Axis Milling Machine.Ideal when you want one machine for many different applications. There is easy transition between manual two-axis CNC, three-axis CNC, and three-axis DNC. Twice as heavy as standard knee mills. More rigidity, stability, and capability.When needed, the TRAK DPM operates as a three-axis CNC mill. The easy-to-use TRAK A.G.E. 3 gives you the capability you need in a CNC that is easy to learn and operate. Used this way, it is outstanding for light to moderate quantity production, as well as complicated three-axis geometry as in mold making.
* TRAK A.G.E. 3 Auto Geometric Engine CNC Three Axis Control.
* Independent Quill Operation.
* Integrated Ram and Quill Encoders.
* Solid Ram Moves Up and Down for Z-axis Operation, Providing Mass Behind Heavy Cuts.
* Wide Way Surfaces / Hardened and Ground.
* Slide Ways are Turcite Coated.
* Handwheels So You Can Work Manually.
* Precision Ground Ballscrews - Table, Saddle and Column.
* Auto Geometry Engine makes calculations for you while you program.
* Diameter Cutter Compensation allows programming of the actual part rather than the center of the tool path.
* 3 Axis Circular Interpolation makes arcs and any size hole easy to do with standard tools.
* Linear Interpolation to machine diagonals at any angle.
* Conrad provides automatic corner radius programming for inside or outside corners with one data input.
* Incremental and Absolute programming can even be mixed within a single event.
* Error Messages to identify programming mistakes.
* Fault Messages for system self-diagnostics.
* Program Down loading from offline CAD/CAM systems.
* Teach to program manual position and mill moves.
* Mirror Image and Rotation of programmed events.
* Software Programmable keys for uncomplicated procedures.
* 3-D Graphics displayed before machining or during program run (real time).
* Look a single button press to view graphics during programming.
* Math Help for finding points in prompted format with graphical representation of prompts.
* Convenient Edit function for recalling and revising program data, adding and deleting events.
* Tool Stepover adjustable for pocket routines.
Trak A.G.E. 3 Control Features:
* Flexible - Easy transition between manual and two or three-axis CNC operation as required by the task at hand. The machinist is never stuck with doing things the "CNC way" if manual is better.
* The Auto Geometry Engine - Embeds CAD capability in part programming, making programming easy by eliminating the need to calculate print dimensions.Programming Canned Cycles:
* Bolt Hole - series of points evenly spaced around a circle
* Mill - straight line in any direction
* Arc - any portion of a circle
* A.G.E. Profile - series of connected lines and arcs defined with limited print data
* Pocket - a rectangle, polygon, circle or irregular shape and all the material inside, includes finish cut
* Frame - a perimeter of a rectangle or circle, includes finish cut
* Sub - repeat of programmed events with or without offset, mirror image or rotation
Table Load Weight: 1,320 lbs.Travels:
Saddle Travel (Y-Axis): 17"
Head Travel (Z-Axis): 23.5"
Throat Distance: 19" (from column ways)
Table to Spindle Nose: 23.5" max.
Spindle Speeds Range: 70 - 4,200 rpmGeneral:
Electrical: 220 Volt, Three Phase (for spindle and servos) / 115 Volt, Single Phase (for control)
Overall Dimensions: 69" x 78" x 85" tallComes as shown in pictures.
