LOT 2 KMC CONTROL RESET VOLUME CONTROLLER CSC-2003 NEW
Lot of 2 KMC Controls Reset Volume Controller, Direct Acting, HVAC Component
The KMC CSC-2000 Series Reset Volume Controllers are designed for use on VAV terminal units in HVAC systems.
The CSC-2000s are sub-master air velocity controllers with adjustable minimum and maximum velocity limits. A master controller, typically a room thermostat, resets the CSC velocity setpoint.
Direct acting models are for normally open VAV terminal units. Reverse acting are for normal closed VAV terminal units.
Each unit is equipped with separate adjustment knobs for minimum and maximum airflow settings. CSC-2001/2002s are equipped with 0 10 reference dials, while all others have blind adjustments. Calibrate all models using standard airflow measuring equipment.
