24VDC hydraulic trailer kit to lift 3.9 tonne 800MM


24vdc Hydraulic Trailer / Tipper Kit To Lift 3.9 Tonne 600mm - ZZ000748
This all in one hydraulic trailer kit consists of the following, easy to assemble, components which will allow you to lift a weight of up to 3.9 tonnes to a height of 800mm
* 24vdc single acting powerpack complete with 2 button pendant.
* 800mm stroke single acting cylinder.
* 3 metres of hydraulic hose.
* 5 litre carton of hydraulic ISO32 oilAdaptors and washers to fit hose to cylinder and powerpack.
TECHNICAL DETAILS ON POWERPACK AS FOLLOWS:-
* 1.6kw 24vdc electric motor c/w relay and plastic motor cover.
* 4.3 Litre reservoir c/w drain plug.
* Reservoir c/w suction strainer, return oil conveyor and filler breather.
* Horizontal mounting Max pressure 220 bar.
* Max flow 4 l/min at 220 bar.
* Main relief valve adjustable from 50 - 220 bar.
* 24vdc let down valve, relief and P line check.
* Suitable for all single acting applications.
* 2 Button pendent on a 4 metre lead.
TECHNICAL DETAILS ON SINGLE ACTING CYLINDER AS FOLLOWS :-
* Closed Centre pin hole to pin hole 1000mm
* Open Centre pin hole to pin hole 1800mm
* Max working pressure 200 bar.
Temperature -30 deg. C to 90 deg C
We specialise in all types of hydraulic components. We have the latest hydraulic components and equipment, with fully trained experienced hydraulic technicians who work with hydraulic components and applications on a daily basis.
In the unlikely event that a return is requested, all returns must include all original items undamaged, in re-saleable condition, all original packaging including manuals, warranty forms, etc.
All products have 12 months warranty.
Rest assured your information will not be given, sold, rented or loaned to any third party.
If you would like any additional information please feel free to contact us:
